IP1131 IP Phone

image title

IP1131 IP Phone

IP1131 IP Phone is a functional IP phone model developed to provide users with maximum convenience and efficiency in communication. Two Ethernet ports with Gigabit support and three VoIP lines ensure reliable and fast communication even during heavy data traffic. Easy to install and update, it features a 132x64 pixel backlit graphic display and HD sound quality. With its user-friendly interface, it offers uninterrupted communication anywhere with internet access.

  • Features

    • Audio Features

      • HD voice: HD handset, HD speaker
      • Wideband codec: G.722
      • Narrowband codec: G.711(A/µ), G.729AB,G.726, iLBC
      • DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO
      • Full-duplex hands-free speakerphone with AEC
      • VAD, CNG, AEC, PLC, AJB, AGC



      Display and Indicator

      • 132x64-pixel graphical LCD with backlight
      • LED for call and message waiting indication
      • Dual-color (red or green) illuminated LEDs for line status information
      • Intuitive user interface with icons and soft keys
      • National language selection
      • Caller ID with name, number



      Phone Features

      • 3 SIP accounts
      • Call hold, mute, DND
      • One-touch speed dial, hotline
      • Call forward, call waiting, call transfer
      • Group listening, SMS
      • Redial, call return, auto answer
      • Local 3-way conferencing
      • Direct IP call without SIP proxy
      • Ring tone selection/import/delete
      • Set date time manually or automatically
      • Dial plan, off hook hot line
      • XML Browser, Action URL/URI
      • Integrated Screenshots
      • RTCP-XR
      • Multi-Language Support: Turkish, English, Arabic, Chinese, Spanish, Hindi, Portuguese, Russian, Japanese. Also, any translation can be added upon request.



      Directory

      • Local phonebook up to 1000 entries
      • Black list
      • XML/LDAP remote phonebook
      • Intelligent search method
      • Phonebook search/import/export
      • Call history: dialed / received / missed /forwarded



      IP-PBX Features

      • Busy Lamp Field (BLF)
      • Bridged Line Apperance(BLA)
      • Anonymous call, anonymous call rejection
      • Hot-desking, emergency call
      • Message Waiting Indicator (MWI)
      • Voice mail, call park, call pickup
      • Intercom, paging, music on hold
      • Call completion, call recording



      Network and Security

      • SIP v1 (RFC2543), v2 (RFC3261)
      • Call server redundancy supported
      • NAT transverse: STUN mode
      • Proxy mode and peer-to-peer SIP link mode
      • IP assignment: static/DHCP
      • HTTP/HTTPS web server
      • Time and date synchronization using SNTP
      • UDP/TCP/DNS-SRV(RFC 3263)
      • QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
      • SRTP for voice
      • Transport Layer Security (TLS)
      • HTTPS certificate manager
      • AES encryption for configuration file
      • Digest authentication using MD5/ MD5-sess
      • OpenVPN, IEEE802.1X
      • IPv6



      Feature Keys

      • 3 line keys with LED
      • 5 features keys: message, headset, redial, tran, hands-free speakerphone
      • 6 navigation keys
      • Volume control keys



      Management

      • Configuration: browser/phone/ auto-provision
      • Auto provision via FTP / TFTP / HTTP / HTTPS for mass deploy
      • Auto-provision with PnP
      • Phone lock for personal privacy protection
      • Zero-sp-touch, TR-069
      • Reset to factory, reboot
      • Package tracing export, system log

  • Details

    • Other Physical Features

      • Wall mountable
      • External universal AC adapter (optional): AC 100~240V input and DC5V/600mA output
      • Power consumption (PSU): 0.72-1.56W
      • Power consumption (PoE): 0.96-1.98W
      • Dimension(W*D*H*T): 209mm * 188mm * 150mm * 41mm
      • Operating humidity: 10~95%
      • Operating temperature: -10~50°C
