The DB211 IP DECT Extension Base Station allows users within the coverage area to communicate with high voice quality and security. It offers freedom of movement with high performance, especially for businesses such as factories, warehouses, hospitals, hotels and shopping malls that require demanding and intensive wireless communication solutions.
Karel DB211 IP DECT Internal Base Station meets your wireless system needs in your workplace with its modular structure and the maximum number of base stations and handheld units it supports. DB211 IP DECT Internal Base Station, which allows 8 simultaneous calls, is compatible with all Karel switchboards including analog, digital and IP. DB211 can be configured to suit the coverage area and number of users.
Supports handover and roaming. The call can be started at any point in the coverage area and can be continued on the move thanks to the handover feature. Thanks to the roaming feature, the user can use the same handset in a different location with the same subscriber number without any additional settings.
Expandable up to 2,047 base stations and 100,000 handheld units by adding base stations and handheld units. Base stations located in the head or other offices are accessible via any Internet browser, which allows independent system management.
DB211, which is the base station of the Karel IP-DECT system, connects to the PBX via IP standards. It broadcasts on DECT standards to connect PBX and the hand units as wireless.
DB211, which was designed for indoor usage, is able to work outdoors with special protective equipment. DB211 is accessible from anywhere via an Internet browser and IP access, allowing to make any necessary system changes.
TECHNICAL SPECIFICATIONS
- DECT GAP/CAP radio communication
- IP connection interface
- 8 calls at a time support
- SIP and H.323 protocols support.
- G.711, G.723.1, G.729A Codec Support
- Advanced DECT Safety (ETSI TS 102 841, GAP.N.35)
- Web Based Management
- Power over Ethernet support (Adaptor support included.)
- Handover and Roaming support
- Status LED flashes
- Internal antennas
- Available for usage with external antenna (DB212)
- Frequency Range 1.880 - 1.900 MHz.
- Coverage Area: ~ 300m (Indoors) / ~50m (Outdoors)
- Power adaptor not included. Adaptor : DB211
